![TYTAN MOBILE GROUND STATION — FINAL IMAGE GENERATION PROMPT
Create a highly realistic, technically accurate isometric cutaway illustration of a custom Mercedes-Benz Sprinter mobile flight-test ground station.
Use the attached Mercedes-Benz PDF as the vehicle reference and the attached original TYTAN TECHNOLOGIES logo for branding.
CRITICAL: Follow the interior arrangement below exactly. Spatial accuracy is more important than visual creativity.
1. Vehicle specifications
* Mercedes-Benz Sprinter PRO 311 CDI, long wheelbase, high roof, rear-wheel drive.
* Exterior: 6,967 mm long × 2,020 mm wide × 2,620 mm high.
* Wheelbase: 4,325 mm.
* Cargo compartment: 4,410 mm long × 1,787 mm wide × 2,010 mm high.
* Deep black exterior paint.
* 16-inch alloy wheels.
* Right-side sliding door.
* One fixed side window on each side behind the cab.
* Two rear cargo doors.
Do not add extra windows, doors, or seats.
2. MANDATORY TOP-VIEW BLOCK DIAGRAM
FRONT OF VEHICLE AT TOP. REAR DOORS AT BOTTOM.
FRONT / WINDSHIELD
↑
┌─────────────────────────────────┐
│ DRIVER PASSENGER PASSENGER │
│ ↑ ↑ ↑ │
│ │
├─────────────────────────────────┤
│ │
│ SECOND ROW BENCH │
│ │
│ [SEAT] [SEAT] [SEAT] │
│ ↑ ↑ ↑ │
│ │
│ ALL THREE FACE FORWARD │
│ │
╞═════════════════════════════════╡
║ WALL A ║
║ FULL WIDTH, FLOOR TO CEILING ║
╞═════════════════════════════════╡
│ │
│ [MONITOR 1][MONITOR 2][MONITOR 3]│
│ │
│ ┌─────────────────────────────┐ │
│ │ COMPUTER DESK │ │
│ └─────────────────────────────┘ │
│ │
│ OPERATOR SEAT │
│ ↑ │
│ FACING THE MONITORS │
│ │
│ ECOFLOW UNDER SEAT │
│ │
│ │
│ NO WALL — NO DOOR — OPEN SPACE │
│ │
│ ┌────────┐ ┌────────┐ │
│ │ LEFT │ │ RIGHT │ │
│ │SHELVES │ │SHELVES │ │
│ │ │ │ │ │
│ │ │ CENTER │ │ │
│ │ │ AISLE │ │ │
│ │ │ │ │ │
│ │ │ DRONE │ │ │
│ │ │ CASES │ │ │
│ └────────┘ └────────┘ │
│ │
├────────────────┬────────────────┤
│ REAR DOOR │ REAR DOOR │
└────────────────┴────────────────┘
REAR
3. Critical interior layout
The exact front-to-rear sequence is:
Three front seats → Three-seat crew bench → Wall A → Computer desk and three monitors → One operator chair → Open storage area with shelves on both sides → Rear doors.
There is ONLY ONE interior partition: WALL A.
Front seating
* Three original front cab seats: driver and two passengers.
* Directly behind them, one factory three-person crew bench.
* All six passenger seats face forward toward the windshield.
* The second-row bench is directly in front of Wall A.
Wall A
* One solid transverse partition immediately behind the second-row bench.
* Runs across the full vehicle width.
* Extends from floor to ceiling.
* The workstation is installed on the REAR FACE of this partition.
Computer workstation
* Three 24-inch monitors mounted side by side on Wall A.
* Monitors face the rear of the vehicle.
* Full-width transverse desk, 450 mm deep, 800 mm high.
* Monitors approximately 1,680 mm wide in total.
* Original illuminated TYTAN logo above the monitors.
* Overhead locker containing radio and networking equipment.
* Cortex computer, network switch, and power strip under the desk.
* Nothing mounted on the longitudinal side walls in the workstation area.
Operator chair
* Exactly ONE swivel operator chair.
* Located behind the computer desk.
* Faces FORWARD toward the windshield and the monitors.
* Its backrest faces the rear doors.
* Mounted on a ventilated pedestal box measuring 760 × 400 × 470 mm.
* EcoFlow DELTA Pro 3 power station (693 × 341 × 410 mm) installed INSIDE the pedestal, directly underneath the chair.
* Show the EcoFlow through a cutaway opening in the pedestal.
Open rear storage — NO SECOND WALL
IMPORTANT CHANGE: WALL B HAS BEEN COMPLETELY REMOVED.
There is absolutely NO partition, NO door, and NO barrier between the operator chair and the rear storage area.
The operator workstation and rear storage occupy one continuous open space behind Wall A.
The operator must be able to approach and access the workstation directly from the rear cargo doors through the central aisle.
Behind and alongside the operator area, install:
* Four-level aluminium shelves on the LEFT side.
* Four-level aluminium shelves on the RIGHT side.
* Shelf depth approximately 400 mm.
* Shelving positioned above the rear wheel arches.
* An open central aisle approximately 990 mm wide.
* Rugged drone transport cases on the rear floor.
* A small electrical distribution box in the rear storage area.
* Blue CEE 230 V / 16 A power inlet at the lower left rear exterior.
Do not place a wall or door between the operator and the shelves.
4. Roof equipment
* Aluminium platform roof rack approximately 4.5 m long.
* Rack approximately 100 mm above the roof.
* White 230 V rooftop air-conditioning unit approximately 1,000 × 760 × 240 mm, above the operator area.
* GNSS puck antenna near the front of the rack.
* LTE/5G shark-fin antenna near the rear.
* Two whip datalink antennas at the rear rack corners.
* At least 1 m separation between antennas and the AC unit.
* Sealed roof cable entry and ceiling cable tray to the workstation.
5. Branding
Use the uploaded TYTAN TECHNOLOGIES logo exactly as supplied.
Place it on:
* Both exterior side panels.
* Both rear cargo doors.
* The illuminated console panel above the monitors.
Do not redraw, distort, recolor, or redesign the logo.
6. Camera and visual presentation
Produce one professional technical presentation image with:
* Main isometric cutaway viewed from above the LEFT side.
* Front of vehicle on the LEFT of the image.
* Rear of vehicle on the RIGHT.
* Selectively removed left-side bodywork and roof to reveal the full interior.
* Clearly visible longitudinal arrangement of the six passenger seats, Wall A, monitors, desk, operator chair, and open storage.
* A smaller TOP-DOWN VIEW showing the identical layout.
* Clean white background.
* Photorealistic materials and precise engineering linework.
* Accurate Mercedes-Benz Sprinter proportions.
* No people.
Include dimension arrows for:
* 6,967 mm overall length.
* 2,020 mm overall width.
* 2,620 mm overall height.
* 4,410 mm cargo compartment length.
7. Numbered legend
1. Three-seat crew bench
2. Wall A — only interior partition
3. Computer desk
4. Three 24-inch monitors
5. Cortex computer
6. Operator chair
7. EcoFlow DELTA Pro 3 inside chair pedestal
8. Open operator-to-storage passage — NO WALL
9. Left and right storage shelves
10. CEE 230 V / 16 A power inlet
11. Rooftop air-conditioning unit
12. Roof rack and antennas
8. Strict prohibitions
DO NOT:
* Add Wall B.
* Add any partition behind the operator chair.
* Add any interior door between the workstation and storage.
* Put monitors on the side walls.
* Rotate the workstation desk along the van length.
* Make the operator chair face backward.
* Put the EcoFlow beside the chair.
* Add a second operator chair.
* Reverse the crew bench.
* Block the central passage from the rear doors to the operator chair.
* Change the original TYTAN logo.
* Invent extra vehicle features.
FINAL VALIDATION: The entire area behind Wall A must be ONE CONTINUOUS OPEN INTERIOR. The computer workstation is at the front of this open area, the operator chair faces forward toward the monitors, and storage shelves run along the left and right sides toward the rear doors. There is NO WALL B and NO SECOND INTERIOR DOOR.
Generate the final engineering cutaway image according to this exact arrangement.](https://s.bananapie.ai/cdn-cgi/image/width=640,quality=75,format=auto,onerror=redirect/cmvb2reei000w06k0pnnplcw9/20261016/cmvb2v26m000e06kz0n5q6ec3-0.png)
